| Type | 8 zone touchscreen wall controller |
| Display | 8-inch, IPS, Capacitive, 10 multi touchpoints, tempered glass, impact resistant to IK2 standard |
| Resolution | 1280 x 800, 189 DPI |
| Data Protocol | Ethernet |
| WebApp System Connection | Ethernet via RJ45 adaptor / Wireless |
| Power | Power over Ethernet (POE) or optional 12V adaptor |
| Computing | Allwinner A133 Quad-Core Cortex-A53 @ 1.5GHz 2GB RAM OS - Android 11 |
| Enclosure | Satin finished ABS, UL94, V0 rated material |
| Colour | Black |
| Mounting System | Supplied with surface mount plate, compatible with EU, US and UK back boxes |
| Dimensions | (W) 146mm x (H) 86.2mm x (D) 39.3mm (W) 5.75" x (H) 3.39" x (D) 1.55" |
| Weight | 0.35kg (0.8lbs) |
